Welcome to the world of Diamond and CBN Industrial Tools-Zhengzhou Shine Abrasives Co.,Ltd from China.
 |
| Place of Origin: | CHINA |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 1A1 |
| Minimum Order Quantity: | 2 PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | 1 pcs in one paper box |
| Delivery Time: | 5 working days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 PCS per week |
| Shape: | 1A1 Straight | Diameter: | 4 Inch 100mm |
|---|---|---|---|
| Bond Type: | Hybrid | Grit Size: | D64 |
| Diamond Rim Size: | 10x10mm | HS Code: | 6804211000 |
| Highlight: | Shine Abrasives CNC Grinding Wheels D64,Shine Abrasives D64 1A1 Diamond Wheel,Shine Abrasives Grinding Wheel D64 1A1 |
||
CNC Grinding Wheel 1A1 Diamond Wheel For Carbide Round Tools Fluting
Shine Abrasives CNC Grinding Wheel, Diamond wheel For Carbide round tools Flute Grinding
Flutes are the helical or straight grooves in the body of the round tool. it provides a pathway to permit the removal of chips,
allow coolants to reach the cutting surface.
Wheels work on 5-axis CNC grinder, wheels are available for CNC grinder of Anca, Makino, Rollomatic, Star, Walter,
and other CNC grinding systems
The drawing of Shine Abrasives CNC Grinding Wheel 1A1 Diamond Wheel For Carbide Round Tools Fluting
Main sizes form of Shine Abrasives CNC Grinding Wheel 1A1 Diamond Wheel For Carbide Round Tools Fluting
| Abrasive Material:Diamond | Bond Type:Hybrid |
| CBN Grit:D64 | Wheel Diameter: 4inch 100mm |
| Wheel Bore:20mm | Wheel Weight:1.5kgs/PC |
| Wheel Thickness:10mm | Concentrate: 125% |
| Wheel core material:Steel. | Diamond section size:10x10mm |
Other standard sizes also are available as requested.
The Super Abrasives Combination for Round Tools Grinding.
General Application parameters recommended.
Wheel Speed:3,000-5,000 SFPM
Infeed Rate:2" - 8" per minute
Depth of Cut:Up to 0.220"
Coolant:Oil or water soluble.
Application picture for reference.
