Welcome to the world of Diamond and CBN Industrial Tools-Zhengzhou Shine Abrasives Co.,Ltd from China.

|
| Place of Origin: | CHINA |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 6A2C Cup |
| Minimum Order Quantity: | 2 PCS |
|---|---|
| Price: | Negotiate |
| Packaging Details: | 1 pcs in one paper box |
| Delivery Time: | 5 working days |
| Payment Terms: | Negotiate |
| Supply Ability: | 10000 pcs per week |
| Shape: | 6A2C Cup | Diameter: | 6 Inch 150mm |
|---|---|---|---|
| Bond Type: | Resin | Grit Size: | 150 Grit |
| Diamond Rim Size: | 20x3mm | Country Of Origin: | China |
| Highlight: | 6A2C Resin Bond Diamond Wheels,Resin Bond Diamond Wheels 150mm,6A2C resin bond grinding wheel |
||
Resin Bond Diamond Cup Wheel 150mm For Carbide Grinding Or Sharpening
Shine Abrasives Resin Bond Diamond Cup Wheel 150mm is suitable for grinding carbide materials.
The drawing of Shine Abrasives Resin Bond Diamond Cup Wheel 150mm For Carbide Grinding Or Sharpening
Specifications of Shine Abrasives Resin Bond Diamond Cup Wheel 150mm
For Carbide Grinding Or Sharpening
| Abrasive Material:Diamond | Bond Type:Resin |
| Diamond Rim Size:20x3mm | Diamond Grit:150 grit, |
| Concentration:125% | Wheel Diameter: 6inch 150mm |
| Wheel Thickness:25mm | Wheel Bore: 1-1/4 inch/31.75mm |
| Wheel Type:6A2 Cup | Wheel Weight:1.0kgs/PC |
Question
How to dressing the resin bond super abrasives grinding wheels?
They are usual 2 methods to dressing the resin bond super abrasives grinding wheels.
1:
Dressing by the white aluminum oxide sticks for CBN wheels,
and silicon carbide sticks for diamond wheels, it's manual as below picture.
2:
Dressing by a silicon carbide abrasive wheel on a special device with a centrifugal brake.
Contacting with the grinding wheel, the truing wheel turns, due to braking, it slips relative to the grinding wheel,
“opening” its working surface and decreasing its run-out at the same time.
Like blow picture.
The wheels are also dreessing by Diamond dresser sometimes.
