Welcome to the world of Diamond and CBN Industrial Tools-Zhengzhou Shine Abrasives Co.,Ltd from China.
 |
| Place of Origin: | China |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 4V2 1A1 14A2 |
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | FOB |
| Packaging Details: | one in paperbox |
| Delivery Time: | 5 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 PCS in one week |
| Wheel Hardness: | Soft, Medium, Hard | Compatibility: | Metal/Ceramic/Glass |
|---|---|---|---|
| Bore: | Various Bores Available | Wheel Type: | Straight |
| Product Type: | Diamond Wheels | Max Speed: | Customized |
| Wheel Hole Number: | Varies | Wheel Grade: | Fine |
| Cooling Method: | Dry, Wet | Size: | Required |
| Hole Diameter: | Customized | Type: | Flat |
| Design: | Standard, Customized | Wheel Quality: | High |
| Grit Range: | Coarse To Fine | ||
| Highlight: | 4A2 Resin Bond Diamond Grinding Wheel,Resin Bond Diamond Grinding Wheel |
||
4A2 diamond grinding wheels used for sharpening and finishing of front Surface of multiple-blade tools.
Mainly used for top, face and side Grinding the circular saw blades and band saws made of tungsten carbide, high Speed steel, cermet and PCD; processing woodwork drills and mills.
| D | T | H | X | V | |||
| mm | Inch | mm | Inch | state bore dimension | mm | Inch | 70° |
| 75 | 3 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 100 | 4 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 125 | 5 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| 150 | 6 | 35 | 1-1/4 | 3-6 | 1/8-1/4 | ||
| Other dimensons are available on request | |||||||
Main Features
High grinding efficiency
Good shape keeping
Good surface quality and consistency of dimension of the Workpiece
High durability and long life
