Welcome to the world of Diamond and CBN Industrial Tools-Zhengzhou Shine Abrasives Co.,Ltd from China.
 |
| Place of Origin: | China |
| Brand Name: | Shine Abrasives |
| Certification: | ISO |
| Model Number: | 4V2 1A1 14A2 |
| Minimum Order Quantity: | 2 pcs |
|---|---|
| Price: | FOB |
| Packaging Details: | one in paperbox |
| Delivery Time: | 5 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1000 PCS in one week |
| Features: | Resin+Diamond + Metal | Coolant: | Synthetic Diamond |
|---|---|---|---|
| Wheel Grit: | 240-700 | Life Span: | Long |
| Bonding: | Resinoid,vitrified | Wheel Shape: | Varies |
| Abrasive Type: | Diamond | Color: | White |
| Wheel Application: | Varies | Edge Retention: | High |
| Cutting Speed: | High | Grain: | Mono-crystalline, Polycrystalline |
| Wheel Speed: | Customized | Style: | 1V1 |
| Wheel Bond: | Resin | ||
| Highlight: | 4V2 Resin Bond Diamond Grinding Wheels,Diamond Grinding Wheels for Woodworking Industry |
||
Shine Abrasives 4V2 resin bond diamond grinding wheels of the most important is that it is very cost effective. It is more competitive than Vitrified bond and Metal Bond. So it is broadly applied in the grinding industries.Diamond works better for carbide, CBN works better for HSS.
| Shape | D(mm) | T(mm) | H(mm) | X(mm) | W(mm) |
| 4V2 | 100 | 25-40 | 16,20,31.75,32 | 2-6 | 3-10 |
| 125 | 25-40 | 16,20,31.75,32 | 2-6 | 3-10 | |
| 150 | 25-40 | 16,20,31.75,32 | 2-6 | 3-10 | |
| We can customize the grinding wheel based on your grinding wheel drawings and model size information. | |||||
Product Features:
1.High cutting efficiency, good self-sharpening, less blocking, reducing the grinding burn occurs when the phenomenon of work
2. Good flexibility will help to improve the surface roughness, mainly used for rough grinding, semi-fine grinding, polishing and other processes
3.Compared to conventional silicon carbide , resin diamond wheel has good material removal rates, longer wheel life and lower grinding costs
4.Resin bond diamond wheels generally remove material up to 10 times faster than metal bond wheels.
